220V motor contactor (CJX2 1801)
The CJX2 1801 motor contactor is a robust and reliable industrial automation component designed to control electric motors in equipment such as tyre changers, wheel balancers and car lifts. Thanks to its versatility and durability, it is ideal for both professional workshops and smaller service shops.
The CJX2 1801 operates with a coil voltage of 220V AC and a frequency of 50/60 Hz, ensuring wide compatibility with industrial and automotive electrical installations.
Equipped with 3 poles and 1 NO (normally open) auxiliary contact, the contactor supports up to 18A rated current at operating voltages up to 380V AC. The high overvoltage resistance (Uimp 6 kV) and 25A thermal current guarantee safe and stable operation even under demanding conditions.
The picture shows the CJX2 1801 contactor with dimensions of approximately 79 x 44 x 71 mm.
Application:
- tyre changers
- wheel balancers
- vehicle lifts
- other industrial equipment requiring reliable motor control
Compatible with many models of workshop machinery - the ideal choice for service shops that value durability and operational safety.
Technical specifications:
- Type: CJX2 1801
- Coil voltage: 220V AC
- Frequency: 50/60 Hz
- Rated current: 18A
- Operating voltage: up to 380V AC
- Thermal current (Ith): 25A
- Surge resistance (Uimp): 6 kV
- Auxiliary contacts: 1 NO
- Number of poles: 3
- Mounting: 35 mm DIN rail
- Housing colour: Black with blue elements
Product code:
P-STYC-0002
By choosing the CJX2 1801 contactor, you are investing in a proven component that will ensure long-term, safe and trouble-free operation of your workshop machinery.
Product safety
Manufacturer
Graf-Art Sławomir Kulbida
ul. Bolesława Chrobrego 38/5
59-700 Bolesławiec, Poland
