Replacement ATH-Heinl: Pedal return spring 460, 1460, 900, 1900, 980, 1980, M32, M52, M72, M72Z
Shipping costs are not included in the price.
Shipping costs are not included in the price.
Product code: ath-47
Share the product card
Ask about the product
The personal data controller is Graf-Art Sławomir Kulbida. We process it to respond to the inquiry. More information about the processing of personal data can be found in the privacy policy.
ATH-Heinl replacement – Pedal return spring for 460, 1460, 900, 1900, 980, 1980, M32, M52, M72, M72Z tyre changers
High-quality pedal return spring for tyre changers of the renowned ATH-Heinl brand. The product is fully compatible with models: 460, 1460, 900, 1900, 980, 1980, M32, M52, M72, M72Z.
Made of blackened spring steel, which is resistant to wear and deformation, ensuring a long service life even under heavy use in workshop conditions.
The spring is responsible for the automatic return of the pedal to its initial position, which is crucial for operator safety and comfort.
Application
The product is used in the pedal mechanism of tyre changers. Replacing the worn spring restores full functionality of the machine, eliminating the risk of the pedal jamming and increasing work efficiency.
Technical specifications
- Overall length: approx. 50 mm
- Outer diameter: approx. 20 mm
- Wire diameter: approx. 2.5 mm
- Material: spring steel, blackened
- End type: closed eyelets on both sides
Compatibility
The spring fits the following ATH-Heinl tyre changer models:
- 460
- 1460
- 900
- 1900
- 980
- 1980
- M32
- M52
- M72
- M72Z
Perfectly matched to original ATH-Heinl components – quick installation and reliable operation without the need for modification.
Product advantages
- High resistance to wear
- Precise operation of the pedal mechanism
- Easy and quick installation
- Equivalent to the original ATH-Heinl part
- Long service life even under intensive use
The pedal return spring is an essential component for every workshop technician. Replacing it is a quick way to restore the machine's performance and ensure safe operation in the workshop.
Product image
Below is an image of the pedal return spring. You can see its compact dimensions: length approx. 50 mm, outer diameter approx. 20 mm, wire diameter approx. 2.5 mm.
